19kg Hydraulic Bus Bar Hole Punching Tool For Metal Sheet Hole Punching

19kg Hydraulic Bus Bar Hole Punching Tool For Metal Sheet Hole Punching
19kg Hydraulic Bus Bar Hole Punching Tool For Metal Sheet Hole Punching 19kg Hydraulic Bus Bar Hole Punching Tool For Metal Sheet Hole Punching

Large Image :  19kg Hydraulic Bus Bar Hole Punching Tool For Metal Sheet Hole Punching

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: CH60
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Get the latest
Packaging Details: wooden case
Delivery Time: 3-5work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200sets/day
Detailed Product Description
Model: CH60 Punching Force: 300KN
Throat Diameter: 95mm Apply: Punching Iron And Copper
Hydraulic Pump: CP700 ZCB6-5-A3 Weight: 19kg
High Light:

hydraulic cable crimping tool

,

hydraulic wire crimping tool

Output 30 Ton CH-60 Hydraulic Puncher Hole Punching Tool Hydarulic Tools



Hydraulic Bus bar Hole Punching Tool For Metal Hole Punching CH-60

Item number

Model

(KN)

Punching

force

(MM)

Punching

thickness

(MM)

throat

diameter

(MM)

Hight

(KG)

Weight

(MM)

specification of

matching mold

hydraulic pump

06243 CH-60

300

iron6

copper10

95 350 19

Φ10.5,Φ13.8,

Φ17,Φ20.5

CP-700/ZCB6-5-A3
06244 CH-70 350

iron10

copper12

110 360 35

Φ10.5,Φ13.8,

Φ17,Φ20.5

CP-700/ZCB6-5-A3
06248 CH-80

500

iron16

copper20

115 340 45

Φ16,Φ18,

Φ22,Φ25

ZCB6-5-AB
06249 CH-100 1000

iron18

copper20

135 400 150

Φ25,Φ28,

Φ32,Φ36

ZCB6-5-AB

Explain:The mold size can be customized according to the requirements of the user

Uses:For copper and aluminum and low carbon steel punching,it needs to be equipped with a hydraulic pump.

Features

Operation speed of CH-60 Hydraulic Hole Puncher is fast than electric drill. It only need a few seconds for punching and there is no burr after punching.

With pressing mechanism design, punching precision is good.

With the hydraulic pump as power, it can used in no power site.
